GYFTS GYTS Underground Duct Outdoor Cable Armored PE Sheath Rodent Resistant Fiber Optic Cable Cable
Description
The fibers, 250μmm, are position in a loose tube made of a high modulus plastic. The tube are filled with a water resistant filling compound.A steel wire,sometimes sheathed with ployethylene(PE) for cable with high fiber count,locates in the center of core as a metallic strength member.
Tubes (and fillers) are stranded around the strength member into a compact and circular cable core.The PSP is longitudinally applied over the cable core,which is filled with filling compound to protect it from water ingress,the cable is completed with a PE sheath.
Feature
- Up to 288 fibers.
- Loose tube gel-filled construction for superior fiber protection.
- Aluminum tape armor to protect cable from mechanical damage.
- UV and waterproof design.
Application
- Interbuilding voice or data communication backbone.
- Installed in duct, underground conduit.
Optical Fiber Characteristics
| | G.652.D | G.6555 | 50/125μm | 62.5/125μm |
| Attenuation | @850nm | | | ≤3.0 dB/km | ≤3.0 dB/km |
| | @1300nm | | | ≤1.0 dB/km | ≤1.0 dB/km |
| | @1310nm | ≤0.36 dB/km | ≤0.40 dB/km | | |
| | @1550nm | ≤0.23 dB/km | ≤0.23dB/km | | |
| Bandwidth | @850nm | | | ≥500 MHz·km | ≥200 MHz·km |
| | @1300nm | | | ≥1000 MHz·km | ≥600 MHz·km |
| Numerical Aperture | | | 0.200±0.015NA | 0.275±0.015NA |
| Cable Cut-off Wavelengthλcc | ≤1260nm | ≤1480nm | | |
Technical Data
| Item | Contents | Value |
| Loose Tube | material | PBT/PP |
| diameter | Ф2.2mm |
| Central strength member | material | Steel wire/Steel wire with PE cover |
| diameter | Ф2.0mm |
| Outer sheath | material | MDPE/HDPE |
| Thickness | 1.7mm |
Cable Mechanical characteristic
| Cable type | Diameter
(mm) | Weight
(Kg/km) | Max.Tension | Crush Resistance
(N) | Min. Bending Radius | Storage Temperature
(℃) |
| Long/Short Term | Long/Short Term | Dynamic | Static |
| GYTS, 2~60F | 10.0 | 115 | 1000/3000 | 1000/3000 | 20D | 10D | -20~+70 |
| GYTS, 62~72F | 10.5 | 130 |
| GYTS, 74~96F | 12.0 | 160 |
| GYTS, 74~96F | 14.0 | 220 |
| GYTS, 122~144F | 16.0 | 280 |
FAQ:
Q: Do you provide OEM service ?
A: Yes, we can print your logo or label on the products or on the box.
Q: Can you provide free samples ?
A: Some of low value samples can be free for you, but you need pay for the shipping cost.
Q: How can you guarentee the quality ?
A: Build on our perfect quality management system, all of our products were 100% tested before the shipment.
Q: What is your delivery time ?
A: Generally, sample: 3~5 working days. Formal order: 7-10 working days.
Q: What's your payment terms ?
A: We accept T/T, Western Union, Paypal, L/C
For samples: 100% payment. Formal order: 30%~100% as deposit, balance payment before shipment.
