Hi 1060 Fiber Optic Patch Cord 900um Loose Tube FC APC Connectors 2 Meters Length

Product Categories

TAKFLY COMMUNICATIONS CO., LTD.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Brand Name : OEM

Model Number : Patch cord

Certification : CE, ISO14001, ISO9001, RoHS

Place of Origin : China

MOQ : 10

Price : Can be negotiate

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 3500 pcs/ Month

Delivery Time : 1-3 wks depends on quantity

Packaging Details : sponge+plastic boxes + Export Carton box

Product name : Hi 1060 fiber optic patch cord 900um loose tube FC APC connectors 2 meters length

Wavelegth : 1060nm

Connector : FC APC

Fiber : Hi 1060

Cable diameter : 900um cable

Fiber length : 2 meter

Contact Now

Hi 1060 fiber optic patch cord 900um loose tube FC APC connectors 2 meters length

DESCRIPTION:

FC/APC - FC/ APC simplex HI1060 fiber Patch Cord Jumper, 900 um blue color loose tube, 2.0 m long, FC/APC connectors

0.1-0.17 dB insertion loss, real-time control.

Cable diameter can be customized according to your request. The connector also can be FC UPC blue boot.

Parameter		Unit	Value
Connector Type		-	FC, SC,LC,MU
Center Wavelength		nm	1310/1550	980/1060	850	780
Max. Insertion Loss		nm	0.3	0.5	0.8	0.8
Min. Extinction Ratio at 23℃		dB	23	23	22	22
Min. Return loss	UPC Type	dB	50
	APC Type	dB	60
Fiber Type		-	PM Panda fiber/ SM fiber, etc
Key Orientation		-	Slow Axis
Tolerance for Axis Alignment		deg	±3
Operating Temperature		℃	-20~+70
Storage Temperature		℃	-40~+85

Hi 1060 Fiber Optic Patch Cord 900um Loose Tube FC APC Connectors 2 Meters Length

Ordering Information

1111	-Operating Wavelength:	1550=1550nm,1310=1310nm,......,0850=850nm
2	-Key Orientation:	S=Slow axis, F=Fast axis
333	-Fiber Type:	001=PM1550, 002=PM1310, 003=PM980, 004=Hi1060, 008=SMF-28E
4	-Connector for Input:	0=FC/UPC,1=FC/APC,2=SC/UPC,3=SC/APC,4=LC/UPC,5=LC/APC, N=None
5	-Connector for Output:	0=FC/UPC,1=FC/APC,2=SC/UPC,3=SC/APC,4=LC/UPC,5=LC/APC, N=None
6	-Pigtail Type:	0=250μm bare fiber, 1=900μm loose tube, 2=2.0mm loose tube, 3=3.0mm loose tube
77	-Fiber Length:	00=0.8m, 01=1m, 20=20m
