10 100 1000M Mini Type Industial Media Converter with SFP Port for High Temperature Application

Brand Name : DF/TAKFLY

Model Number : DF-1000M-MC-ID-MINI

Certification : CE/ROHS/FCC/REACH/ISO

Place of Origin : China

MOQ : 1

Price : USD 26.5~USD30.5/PC

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 30000PCS per month

Delivery Time : 5-7 working days

Packaging Details : 1pc in a inner box, several box in a carton

Rate : 10/100/1000M

Fiber Port : SFP, LC

Connector : One UTP RJ-45 connector, one SFP connector, one DC-inlet connector

Operating Voltage : DC 9~56V

Rated Current : 0.5/0.25A

Operating Temperature : -30℃~+75℃

Storage Temperature : -40℃ 85℃

Dimension : 118mm×39mm×26mm

Contact Now



10 100 1000M Mini Type Industial Media Converter with SFP Port for High Temperature Application



This is a Gigabit Ethernet stand-alone Mini Industrial media converter that provides cost effective, entry-level media conversion between 1x10/ 100/ 1000Base-TX ports and 100/ 1000Base-FX ports . With its fixed configuration , deployments are just plug-and-play, and with it is small size , it is ideal for locations where space is limited.



1x10/ 100/ 1000Base Fiber Media Converter, SFP Fiber Media Converter, Options in single mode dual fiber, multimode dual fiber and single mode single fiber.



Takfly is a leading manufacturer of Fiber Optic passive and active products since 2000, with ISO9001 and ISO14001 certified.

All of our products are complied with CE, ROHS, REACH requirement, OEM is available.









Features

  • Unit and Port LEDs allow for quick status information
  • Auto-Negotiation
  • Fixed Full-Duplex on fiber
  • Auto-MDI/ MDIX
  • Automatic Link Restoration
  • Connect to legacy network equipment
  • Eliminate Collision Domains
  • 10/ 100/ 1000Base-TX UTP to 100/ 1000Base-FX fiber media converter
  • Supports IEEE802 .3U IEEE802 .3z 1000Base-TX/FX protocols , IEEE802 .3ab standards
  • SFP Port
  • DIP switch to set different configurations
  • Compact package size
  • Supports IEEE802 .3x flow control; 100Base-FX interface; auto MDI-MDIX function; LFP function; ALS function;The media converter is reset again after the fiber link is disconnected



Specification





Transmission Distance

 Twisted-pa 100M standard CAT5/CAT5e cable SFP, Distance depend on plug-in Fiber Tranceiver
Store-and-Forward Mode 1518Bytes
Pass Through Mode 10KBytes
LFP Mode Support



DIP Switches

LFP function (optional) ALS function (optional) FX Reset (optional)

FX speed (optional)100Base-FX interface
Connector One UTP RJ-45 connector, one SFP connector, one DC-inlet connector
Operation Mode Full duplex or half duplex mode



Power Requirement

 Operating Voltage DC 9~56V Rated Current: 0.5/0.25A





Environmental Requirement

Operating Temperature: -30℃~+75℃

Storage Temperature: -40℃ 85℃

Relative Humidity: 5%~95% (non-condensation)

MTBF: 100,000 h

Enclosure: Metal
Mechanical Structure Dimensions: 118mm×39mm×26mm
Warranty 3 Year
Emissions FCC Class A, CE Class A



10 100 1000M Mini Type Industial Media Converter with SFP Port for High Temperature Application
